AJA HD10CEA HD/SD-SDI to Analog Converter
Compact HD/SD-SDI to analog video and 4-channel audio converter, ideal for digitizing legacy analog content to SDI.
4 in stock
The HD10CEA is a compact HD/SD-SDI to analog converter that extracts analog video and 4-channel balanced audio directly from an SDI signal with embedded audio. It supports YPbPr, RGB, NTSC, PAL and S-Video output formats, with all format, pedestal, blanking and audio-level settings handled through an external dipswitch — no software required.
It's a perfect fit for feeding legacy analog decks, monitors or duplication equipment from a modern SDI source — including transferring older analog archive content to SDI for digitization, where the HD10CEA sits in the signal path to bridge a digitizing/capture chain with equipment that still expects an analog feed. Two equalized SDI loop-through outputs let it pass the signal on to additional gear without a separate distribution amplifier.
At 147 x 79 x 25mm and just 4W, it's a low-footprint way to keep analog-only equipment working inside an otherwise all-SDI facility.
| Input | 1x BNC, SD/HD-SDI with embedded audio |
|---|---|
| Video outputs | YPbPr (SMPTE, EBU-N10, Betacam), RGB, NTSC, PAL, YC (S-Video) |
| Audio output | 4-channel balanced, 25-pin D connector |
| SDI loop-through | 2x BNC, equalized |
| Controls | External dipswitch: video format, pedestal, H/V blanking, audio group, audio level (+24/+18/+15/+12 dBu) |
| Connectors | 25-pin D (video/audio out), 2x BNC (SDI loop) |
| Power | +5-18VDC regulated, 4W (power supply included) |
| Dimensions | 147 x 79 x 25mm (5.8 x 3.1 x 1.0in) |
| Operating temp | 0-40°C |
| Typical use | Feeding legacy analog monitors/decks from SDI; transferring analog archive content to SDI for digitization |
